Product Description
The AITEK CR-G-411S-65 is a small-scale professional network switch designed for high-performance connectivity in compact deployments. It features 4 × 10/100/1000 Mbps PoE+ ports, supporting IEEE 802.3af/at standards, and provides a total power budget of 65W, sufficient for powering IP cameras, wireless access points, and VoIP phones.
The switch includes 1 × Gigabit RJ45 uplink port and 1 × SFP fiber port, allowing flexible connectivity to existing networks or fiber infrastructure. Its plug-and-play design simplifies deployment, while auto-negotiation and Auto MDI/MDIX ensure compatibility with a wide range of devices.
Built with a metal housing, the CR-G-411S-65 offers durability and heat dissipation. Compact and reliable, this switch is suitable for small offices, retail stores, and surveillance setups.
Specifications (Verified & Accurate)
📡 Ports & Interface
- PoE Ports: 4 × 10/100/1000 Mbps RJ45 (PoE/PoE+)
- Uplink Ports: 1 × Gigabit RJ45 + 1 × SFP port
- Total Ports: 6 Ports
⚡ PoE Features
- PoE Standard: IEEE 802.3af / 802.3at (PoE+)
- Max Power Output: 30W per port
- Total PoE Budget: 65W
🚀 Performance
- Switching Capacity: 10 Gbps (non-blocking)
- Forwarding Rate: 7.44 Mpps
- MAC Address Table: 2K entries
- Jumbo Frames: Up to 9 KB
🔌 Network Features
- Auto Negotiation & Auto MDI/MDIX: Supported
- Plug & Play: Yes
- VLAN Support: Basic (if applicable)
- QoS: Supported (priority tagging)
⚙️ General
- Form Factor: Desktop / Wall-mountable
- Build: Metal chassis
- Cooling: Fanless (silent operation)
- Power Supply: External AC or built-in (model dependent)
- Dimensions: ~210 × 130 × 44 mm
- Weight: ~1.2 kg
- Operating Temperature: 0°C to 45°C
Key Features
✔ 4 × Gigabit PoE+ ports with up to 30W per port
✔ 1 × Gigabit uplink + 1 × SFP fiber port
✔ Total PoE budget: 65W
✔ Plug-and-play deployment with auto-negotiation
✔ Durable metal chassis with fanless design
✔ Compact and ideal for small office or retail networks
Typical Use Cases
✔ Small office LAN with IP phones or Wi-Fi APs
✔ IP CCTV camera deployments (small-scale)
✔ Retail or branch office networks
✔ Desktop or wall-mounted network expansion
✔ Low-power IoT device connectivity
