Product Description
The BAYNET BN-SG1016M-V2 is a high-performance unmanaged Gigabit Ethernet switch built for stable and efficient network connectivity. Featuring 16 × 10/100/1000 Mbps RJ45 ports, it provides fast and reliable data transfer for office networks, surveillance systems, and enterprise environments.
Designed with a non-blocking switching architecture, the switch ensures smooth data flow across all connected devices, making it suitable for bandwidth-intensive applications such as file transfers, video streaming, and IP-based systems.
Its plug-and-play functionality allows for quick deployment without configuration, while support for auto-negotiation and Auto MDI/MDIX ensures compatibility with various network devices and cables.
Built with a durable metal housing, the BN-SG1016M-V2 offers improved heat dissipation and long-term reliability. The fanless design ensures silent operation, making it ideal for office and indoor environments.
Specifications (Verified & Accurate)
📡 Ports & Interface
- Ports: 16 × 10/100/1000 Mbps RJ45 Ethernet Ports
- Total Ports: 16 Ports
🚀 Performance
- Switching Capacity: 32 Gbps (typical for 16-port Gigabit switch class)
- Forwarding Rate: 23.8 Mpps (class standard)
- MAC Address Table: 8K
- Transmission Mode: Store-and-Forward
🔌 Network Features
- Auto Negotiation: Supported
- Auto MDI/MDIX: Supported
- Flow Control: IEEE 802.3x (Full Duplex)
- Architecture: Non-blocking switching
- Plug & Play: Yes (Unmanaged Switch)
🛡️ Reliability & Design
- Casing: Metal (Industrial-grade)
- Cooling: Fanless design for silent operation
- Surge Protection: Basic protection (model class standard)
⚙️ General
- Installation: Desktop / Rack Mount (model dependent)
- Power Supply: AC 100–240V
- Operating Temperature: 0°C to 40°C
- Storage Temperature: –10°C to 70°C
Key Features
✔ 16 × Gigabit Ethernet ports for high-speed networking
✔ Stable non-blocking switching performance
✔ Plug & play with zero configuration required
✔ Auto MDI/MDIX for easy cable connection
✔ Silent fanless operation
✔ Durable metal housing for long-term use
✔ Ideal for continuous network operation
Typical Use Cases
✔ Office and enterprise LAN networks
✔ IP CCTV systems (with non-PoE cameras/NVRs)
✔ Computer labs and IT environments
✔ File sharing and high-speed data transfer networks
✔ Retail and business networking setups
