Description

Product Description

The Cisco Catalyst 3750G 48-Port PoE Switch is a high-performance enterprise-class managed switch designed for advanced networking environments. Equipped with 48 × Gigabit Ethernet PoE ports and 4 × SFP uplink ports, it provides scalable connectivity for large networks.

Built with Layer 3 switching capabilities, the 3750G supports routing, VLANs, QoS, and advanced security features, making it suitable for enterprise LAN deployments, campus networks, and critical infrastructure.

The switch supports IEEE 802.3af PoE, enabling power delivery to devices such as IP phones, wireless access points, and IP cameras without additional power supplies. It offers a total PoE budget of up to ~370W, allowing flexible power distribution across ports.

Cisco’s StackWise technology allows multiple switches to be stacked and managed as a single unit, improving scalability and redundancy. With robust build quality and proven reliability, this model remains popular in refurbished and used markets.

⚠️ Note: This is an End-of-Life (EoL) product and typically available as used/refurbished.

Specifications (Verified & Accurate)

📡 Ports & Interface

• Ethernet Ports: 48 × 10/100/1000 Mbps RJ45 (PoE)
• Uplink Ports: 4 × Gigabit SFP
• Total Ports: 52 Ports

⚡ PoE Features

• PoE Standard: IEEE 802.3af
• Max PoE Output: 15.4W per port
• Total PoE Budget: Up to ~370W
• Power Distribution:
  • Up to 24 ports at full 15.4W, or
  • All ports at lower shared power

🚀 Performance

• Switching Capacity: 32 Gbps
• Forwarding Rate: Up to 38.7 Mpps
• MAC Address Table: Up to 12K entries
• Stack Bandwidth: 32 Gbps StackWise

🧠 Management & Features

• Switch Type: Managed (Layer 3)
• Routing: Static routing, RIP, IPv6 support
• VLAN Support: Yes
• QoS: Advanced QoS support
• Security: ACL, RADIUS, SSH, SNMP
• Management: CLI, Telnet, SNMP, Web (limited)

🔌 Network Features

• Auto Negotiation & Auto MDI/MDIX: Supported
• Link Aggregation: LACP / EtherChannel
• Spanning Tree: STP, RSTP, MSTP
• Jumbo Frames: Supported

⚙️ General

• Form Factor: Rack-mountable (1U)
• Build: Metal chassis
• Power Supply: Internal AC
• Cooling: Fan-based (enterprise cooling)
• Condition: Used / Refurbished

Key Features

✔ 48 × Gigabit PoE ports for large-scale deployments
✔ 4 × SFP uplink ports for fiber connectivity
✔ Layer 3 managed switch (routing + VLANs)
✔ Up to ~370W PoE power budget
✔ Cisco StackWise technology for scalability
✔ Enterprise-grade security and QoS features
✔ Reliable performance for critical networks

Typical Use Cases

✔ Enterprise LAN and campus networks
✔ IP telephony systems (VoIP)
✔ Large IP CCTV deployments
✔ Data centers and server rooms
✔ Network labs and training environments
