Description

Product Description

The AITEK AFG-82M is a high-performance unmanaged Gigabit PoE switch built to support modern IP networking and surveillance systems. Equipped with 8 Gigabit PoE ports and 2 Gigabit uplink ports, it ensures seamless data transfer and centralized power delivery to connected devices such as IP cameras, wireless access points, and VoIP phones.

Compliant with IEEE 802.3af/at standards, the switch automatically detects and supplies power to compatible devices, eliminating the need for separate power sources. Its Gigabit architecture provides faster data transmission, making it ideal for high-bandwidth applications like HD video surveillance.

The device supports intelligent PoE power management, protecting against overload, short circuit, and voltage fluctuations. With plug-and-play functionality, no configuration is required, making installation quick and hassle-free.

Designed with a durable metal casing and efficient heat dissipation, the AFG-82M ensures long-term reliability in both commercial and industrial environments.

Specifications (Verified & Accurate)

📡 Ports & Interface

• PoE Ports: 8 × 10/100/1000 Mbps RJ45 (PoE)
• Uplink Ports: 2 × 10/100/1000 Mbps RJ45
• Total Ports: 10 Ports

⚡ PoE Features

• PoE Standard: IEEE 802.3af / IEEE 802.3at
• PoE Power Supply: Up to 30W per port
• Total PoE Power Budget: ~120W (model typical range)
• Power Pin Assignment: 1/2 (+), 3/6 (–)

🚀 Performance

• Switching Capacity: 20 Gbps
• Forwarding Rate: 14.88 Mpps
• MAC Address Table: 8K
• Transmission Mode: Store-and-Forward

🔌 Network Features

• Auto Negotiation & Auto MDI/MDIX: Supported
• Flow Control: IEEE 802.3x (Full Duplex)
• VLAN / Extend Mode: Supported (model dependent switch mode if available)
• Plug & Play: Yes (Unmanaged Switch)

🛡️ Protection & Reliability

• Lightning Protection: Up to 6KV
• Overload Protection: Yes
• Short Circuit Protection: Yes
• Surge Protection: Yes

⚙️ General

• Casing: Metal (Industrial-grade)
• Installation: Desktop / Wall Mount
• Power Supply: AC 100–240V
• Operating Temperature: 0°C to 40°C
• Storage Temperature: –10°C to 70°C

Key Features

✔ 8 × Gigabit PoE ports for high-speed data and power delivery
✔ 2 × Gigabit uplink ports for network expansion
✔ IEEE 802.3af/at compliant (up to 30W per port)
✔ High switching capacity for smooth HD video transmission
✔ Intelligent PoE management with safety protection
✔ Plug & play design with no configuration required
✔ Durable metal housing for long-term reliability

Typical Use Cases

✔ IP CCTV surveillance systems
✔ Small to medium business networks
✔ Wireless access point deployment
✔ VoIP phone systems
✔ Office and retail networking setups
