Description
Product Description
The ALINK Cat6 UTP Cable Roll 305 Meter is a professional-grade networking solution built for reliable and high-speed data communication. Designed with 23AWG solid copper conductors, this cable ensures strong signal integrity, reduced resistance, and stable performance across long distances.
Compliant with Category 6 standards, it supports bandwidth up to 250 MHz and delivers data speeds up to 1 Gbps, making it suitable for modern network applications such as internet, VoIP, CCTV, and enterprise networking.
The cable features 4 pairs of unshielded twisted wires (UTP), reducing crosstalk and interference while maintaining consistent performance. It is supplied in a 305-meter (1000 ft) pull box, making installation easy for structured cabling systems in offices, buildings, and data centers.
Its durable PVC or LSZH jacket provides protection and flexibility, ensuring long-lasting use in indoor environments. This cable is ideal for horizontal and backbone cabling in both residential and commercial networks.
Key Features
- Cat6 UTP cable for high-speed networking
- 305-meter (1000 ft) cable roll
- 23AWG solid copper conductors
- Supports up to 1 Gbps data transfer
- Bandwidth up to 250 MHz
- 4-pair twisted cable to reduce interference
- Easy pull-box packaging for installation
- Durable PVC / LSZH outer jacket
- Suitable for structured cabling systems
Technical Specifications
Cable Type: Cat6 UTP (Unshielded Twisted Pair)
Length: 305 Meter (1000 ft)
Conductor: 23 AWG Solid Copper
Pairs: 4 Pairs
Bandwidth: Up to 250 MHz
Data Speed: Up to 1 Gbps
Impedance: 100 ±15 Ohms
Insulation Material: HDPE
Jacket Material: PVC / LSZH
Cable Diameter: Approx. 6.0 – 6.5 mm
Standards: ANSI/TIA-568, ISO/IEC 11801
Application: Indoor Networking
Use Cases
- Office and enterprise network installation
- CCTV and IP surveillance systems
- Data centers and server rooms
- Structured cabling systems
- VoIP and broadband networks
