Description
📘 Product Description
The Cambium ePMP Force 425 is engineered for reliable, high‑capacity wireless backhaul between remote sites where fiber installation is costly or impractical. Leveraging the latest 802.11ax Wi‑Fi 6 standard and Cambium’s proprietary ePTP protocol, it delivers gigabit‑class speed with low latency (< 5 ms) and excellent spectral efficiency.
It includes a 25 dBi integrated dish antenna for robust long‑range performance, and an optional 28 dBi range extender can be fitted in the field to increase link budget and enable higher modulation performance for challenging links.
With both Gigabit Ethernet (RJ‑45) and an SFP port, the Force 425 supports versatile connectivity including fiber extension and integration into modern network infrastructures. It is built for outdoor deployments with an IP67‑rated rugged enclosure, ensuring durability against dust, rain, and harsh environments.
Deployment, planning, and network monitoring are supported by cnMaestro™ and LINKPlanner, making it simple to design and manage point‑to‑point wireless links for service providers, enterprise networks, and WISP backhaul.
🧾 Specifications
🔊 Wireless / Radio
- Standard: 802.11ax (Wi‑Fi 6), 2×2 MIMO/OFDM
- Proprietary Mode: Cambium ePTP (optimized PTP protocol)
- Frequency Range: 4910 – 6135 MHz (region dependant)
- Channel Widths: 20 / 40 / 80 MHz
- Channel Spacing: 5 MHz increments
- Modulation: Supports up to 1024‑QAM
- ARQ: Yes
📈 Performance
- Maximum Throughput: Up to 1 Gbps
- Latency: < 5 ms
- Transmit Power Range: +3 to +28 dBm (to regional EIRP limit)
📶 Antenna
- Integrated Antenna: 25 dBi dish
- Optional Extender: 28 dBi range extender (sold separately)
🔌 Interfaces & Connectivity
- Ethernet Ports:
• 1 × RJ‑45 Gigabit Ethernet
• 1 × SFP port
🌦️ Environmental & Physical
- Enclosure Rating: IP67 outdoor‑rated
- Surge Suppression: Integrated (~1 J)
- Power Consumption: ~28 W
🛠️ Management & Security
- Security: 128‑bit AES over‑the‑air encryption (256‑bit where export rules allow)
- Management Tools: cnMaestro™, LINKPlanner
📩 Typical Use Cases
✔ Long‑range point‑to‑point backhaul links
✔ ISP/WISP network backhaul
✔ Enterprise connectivity across buildings
✔ Fiber extension where fiber deployment is limited
