Description

Product Description

The D-LINK DMC-810SSC 1000BASE Single Mode Media Converter is a high-performance Gigabit Ethernet to fiber optic converter designed to extend network distances beyond the limitations of copper cabling. It converts RJ45 Ethernet signals into optical signals, enabling fast and stable communication over single-mode fiber.

Supporting 1000BASE Gigabit speeds, this media converter is ideal for high-bandwidth applications where reliability and performance are critical. It is widely used in enterprise networks, ISP backbone infrastructure, data centers, CCTV surveillance systems, and industrial networking environments.

The DMC-810SSC is designed for single-mode fiber transmission, allowing long-distance connectivity while maintaining low latency and high signal integrity. It eliminates electromagnetic interference (EMI), ensuring clean and stable data transmission over fiber.

With its plug-and-play functionality, the device requires no configuration, making installation quick and simple. Its compact and durable design ensures reliable 24/7 operation in professional networking environments.

Key Features

• Gigabit Ethernet (1000BASE) media converter
• Converts RJ45 Ethernet to single-mode fiber
• Supports 10/100/1000 Mbps auto-negotiation
• High-speed stable fiber transmission
• Plug & Play installation (no configuration required)
• Long-distance fiber network extension
• Strong resistance to EMI/RFI interference
• Low latency and reliable performance
• Compact and durable design
• Suitable for 24/7 continuous operation

Technical Specifications

General

• Model: DMC-810SSC
• Brand: D-Link
• Type: Gigabit Fiber Media Converter
• Speed: 10/100/1000 Mbps (Auto-Negotiation)

Ethernet Interface

• Port: 1 × RJ45 Gigabit Ethernet Port
• Standard: IEEE 802.3, 802.3u, 802.3ab

Fiber Interface

• Type: Single Mode Fiber (SMF)
• Connector: SC (typically used)
• Transmission Distance: Up to 10KM–20KM (depending on fiber module)
• Wavelength: 1310nm (typical for single-mode)

Performance

• Full-duplex Gigabit transmission
• Low latency and stable throughput
• High reliability over long distances

Power

• External DC power adapter
• Low power consumption

Installation

• Plug & Play
• Desktop or rack-mount compatible

Environment

• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Humidity: 5% – 90% RH

Use Cases

• Enterprise Gigabit network extension
• ISP fiber backbone networks
• CCTV surveillance systems (HD/IP cameras)
• Data center connectivity
• Industrial networking environments
• Inter-building long-distance links
