Description

📘 Product Description

The Grandstream GWN7672 represents the next generation of wireless connectivity with Wi‑Fi 7 technology, combining tri‑band support and cutting‑edge features to deliver ultra‑fast and reliable Wi‑Fi performance for enterprise, business, and campus environments. With an aggregate throughput of up to 11 Gbps, this access point is ideal for bandwidth‑intensive applications such as video conferencing, large file transfers, high‑density device connections, and real‑time services.

Built‑in technologies like Multi‑Link Operation (MLO), DL/UL Enhanced OFDMA, 4KQAM modulation, MRU (Multi‑Resource Units), and preamble puncturing enhance spectrum efficiency, reduce latency, and optimize network capacity even in crowded wireless environments. These advancements help the GWN7672 accommodate many simultaneous connections without degradation in performance.

The access point supports advanced Quality of Service (QoS) to prioritise latency‑sensitive traffic (like voice and video), and robust security features including WPA3 and anti‑hacking secure boot with unique device credentials. It also offers flexible management through an embedded controller or scalable tools such as GDMS Networking (cloud‑based) and GWN Manager (on‑premise), making deployment and control straightforward.

🧾 Technical Specifications

📶 Wireless & Performance

• Wireless Standard: IEEE 802.11be (Wi‑Fi 7), tri‑band (2.4 GHz, 5 GHz, 6 GHz)
• Aggregate Throughput: Up to 11 Gbps (BE11000) combined across all bands
• MU‑MIMO & Advanced Technologies:
  • Tri‑band 2x2x2:2 MU‑MIMO
  • Multi‑Link Operation (MLO)
  • DL/UL Enhanced OFDMA
  • 4KQAM modulation
  • Multi‑Resource Units (MRU) & Preamble Puncturing
• Concurrent Clients Supported: Up to 384 Wi‑Fi devices
• Coverage Range: Up to ~175 meters indoor line‑of‑sight
• SSID Support: Up to 48 SSIDs total (16 per band)
• Antennas: 7 internal single‑frequency antennas

🔌 Network Interfaces

• Ethernet: 2 × 5 Gigabit RJ‑45 interfaces (supporting both WAN/LAN use)
• PoE Support: 802.3at / PoE+ with self‑power adaptation
• Maximum Power Consumption: ~25 W (typical)

🔐 Security & Features

• Security Standards: WEP, WPA/WPA2‑PSK, WPA/WPA2 Enterprise (TKIP/AES), WPA3
• Secure Boot & Protection: Anti‑hacking secure boot with digital signatures and unique security credentials per unit
• Advanced QoS: Prioritises low‑latency and real‑time applications
• Management:
  • Embedded controller for local AP management
  • GDMS Networking (cloud‑based)
  • GWN Manager (on‑premise)

🛠 Deployment & Mounting

• Mounting Options: Indoor ceiling or wall mount (kits included)
• Operating Environment: Indoor enterprise/office deployments

📩 Ideal Use Cases

✔ Medium‑to‑high density wireless environments such as offices, campuses, retail, and commercial spaces
✔ High‑bandwidth, low‑latency applications (video streaming, conferencing, cloud services)
✔ Networks requiring strong security and advanced management options
✔ Seamless service for many connected devices (up to 384 concurrent clients)
