Description

Product Description

The NETLINK Media Converter 10/100 is a cost-effective networking solution used to extend Ethernet networks over fiber optic cable. It converts electrical signals from standard RJ45 copper-based Ethernet into optical signals, enabling stable communication over fiber infrastructure.

Supporting Fast Ethernet speeds of 10/100 Mbps, this device is widely used in CCTV surveillance systems, office networks, ISP setups, and industrial networking environments where reliable data transmission is required over longer distances than traditional copper cabling allows.

The media converter eliminates issues such as electromagnetic interference (EMI), signal loss, and distance limitations, ensuring smooth and consistent network performance over fiber.

With plug-and-play functionality, the NETLINK 10/100 media converter requires no configuration, making installation quick and simple. Its compact and durable design ensures stable 24/7 operation in professional environments.

Key Features

• Fast Ethernet media converter (10/100 Mbps)
• RJ45 to fiber optic conversion
• Stable and interference-free data transmission
• Plug & Play installation (no configuration required)
• Suitable for short to medium distance fiber links
• Low latency and reliable performance
• Compact and durable design
• Supports 24/7 continuous operation
• Ideal for CCTV and network extension
• Cost-effective fiber connectivity solution

Technical Specifications

General

• Brand: NETLINK
• Type: Fiber Media Converter
• Speed: 10/100 Mbps Fast Ethernet

Ethernet Interface

• Port: 1 × RJ45 LAN Port (Auto 10/100 Mbps)
• Standard: IEEE 802.3, IEEE 802.3u

Fiber Interface

• Type: Single Mode / Multi Mode (depending on model)
• Connector: SC (commonly used)
• Distance: Up to 2KM–20KM (depending on fiber module)
• Wavelength: 850nm / 1310nm / 1550nm (based on variant)

Performance

• Full-duplex / Half-duplex support
• Low latency transmission
• Stable fiber communication

Power

• External DC power adapter
• Low power consumption

Installation

• Plug & Play
• Desktop or wall-mount compatible

Environment

• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Humidity: 5% – 90% RH

Use Cases

• CCTV surveillance systems
• Office and enterprise networks
• ISP fiber network extension
• Industrial networking environments
• Inter-building short distance connectivity
• Secure data transmission setups
