Description
Key Features
-
16× Gigabit Ethernet RJ45 Ports with 8 PoE+ compliant ports (IEEE 802.3af/at) for powering connected devices like APs, IP cameras, and VoIP phones.
-
2× Gigabit SFP Uplink Ports for fiber expansion and uplink connectivity.
-
Total PoE Budget: 42 W with up to 32 W per PoE+ port under IEEE 802.3at standards.
-
36 Gbps Switching Capacity and 18 Gbps non‑blocking throughput for efficient, high‑speed performance.
-
27 Mpps Forwarding Rate ensures smooth packet processing across all ports.
-
Managed via UniFi Network Controller for centralized provisioning, monitoring, network mapping, and configuration.
-
1.3″ Touchscreen Display for real‑time device status and quick diagnostics.
-
Fanless, Silent Design with rack‑mountable 1U chassis for quiet operation in rack setups.
-
Advanced Layer‑2 features including VLAN support, LACP, STP/RSTP, QoS, IGMP snooping, ACLs, jumbo frames, port mirroring, and storm control via UniFi software.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Ubiquiti UniFi USW‑16‑PoE |
| Ethernet Ports | 16 × 10/100/1000 Mbps RJ45 (8 PoE+) |
| PoE Standards | IEEE 802.3af / IEEE 802.3at PoE+ |
| Total PoE Budget | 42 W |
| Uplink | 2 × 1 GbE SFP |
| Switching Capacity | 36 Gbps |
| Non‑Blocking Throughput | 18 Gbps |
| Forwarding Rate | ~27 Mpps |
| Management | UniFi Network Controller |
| Display | 1.3″ touchscreen |
| Cooling | Fanless, silent |
| Form Factor | 1U rack mount |
| Power Supply | Internal AC 100–240 V |
| Certifications | CE, FCC, IC (NDAA compliant) |
| Operating Temp. | –5 °C to 40 °C |
| Dimensions | 442 × 200 × 44 mm |
Ideal Applications
The Ubiquiti USW‑16‑PoE managed switch is ideal for:
-
Small to medium business networks requiring centralized management and PoE delivery.
-
Enterprise surveillance installations with PoE cameras and uplinked fiber connections.
-
Wi‑Fi and VoIP deployments that need PoE‑powered access points and phones.
-
Rackmount network infrastructures in offices and data closets.
Trust & Performance Highlights
✔ Managed Layer‑2 switching via UniFi Network Controller with advanced VLAN, QoS, and security features.
✔ Flexible PoE+ support for powering network edge devices directly.
✔ Silent fanless operation with intuitive touchscreen display.
✔ Robust rack‑mountable design suitable for professional IT deployments.
