Dahua DH-HAC-HDW1209CLQP-A-LED 2.8MP Dome Camera

Dahua DH-HAC-HDW1209CLQP-A-LED 2.8MP Dome Camera

Category:

Dahua DH‑HAC‑HDW1209CLQP‑A‑LED 2MP Dome Camera — The Dahua DH‑HAC‑HDW1209CLQP‑A‑LED is a versatile 2 MP full‑color HDCVI dome camera offering 1080p Full HD resolution at up to 30 fps with consistent color imaging day and night. It features built‑in LED illumination for clear low‑light performance up to ~20 m, a fixed 2.8 mm wide‑angle lens with broad field of view, and 4‑in‑1 switchable output (CVI/TVI/AHD/CVBS) for flexible DVR compatibility. With DWDR, BLC/HLC and 2D‑DNR enhancements and an IP67 weather‑proof housing, it’s ideal for both indoor and outdoor surveillance in homes, shops, and offices.

Description

MAIN FEATURES:

Image Sensor: 1/2.8 inch 2.16 Mega Pixels CMOS

Effective Pixels: 1920 (H)×1080 (V), 2MP

Electronic Shutter Speed: PAL:1/25s–1/100000sNTSC:1/30s–1/100000s

Minimum Illumination: 0.005Lux/F1.6, 30IRE, 0Lux white Light on

Fill Light Distance: Up to 20m (65.61ft)

Fill Light On/Off Control: Auto/Manual

Pan/Tilt/Rotation Range: Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°

HDW1209TLQP-A-LED Full Color Lens

Lens Type: Fixed-focal

Mount Type: M12

Focal Length: 2.8m

Max. Aperture: F1.6

Angle of View: 2.8mm: 126.2°×106.0°×56.5° (diagonal x horizontal x vertical), 3.6mm: 103.6°x86.9°x46.3°(diagonal x horizontal x vertical)

Brand

Dahua

Reviews

There are no reviews yet.

Be the first to review “Dahua DH-HAC-HDW1209CLQP-A-LED 2.8MP Dome Camera”

Your email address will not be published. Required fields are marked *
